C-tick认证

AC-Tick认证简介

A/C-Tick是由澳大利亚通讯局(Australian Communications Authority, 简称ACA)为了通信设备发的认证标志。制造商和进口商必须依照下更步骤使用A-Tick::

1、产品执行ACAQ技术标准测试

2、向ACA登记使用A/C-Tick

3、填写“符合声明表”(Declaration of Conformity Form),并和产品符合记录保存一起

4、在通信产品或设备上贴上有A/C-Tick标志的标识(label) 5、销售给消费者 A-Tick仅适用于通信产品,电子产品多半是申请C-Tick ,不过电子产品如果申请A-Tick,则不需另外申请C-Tick 。


自2001年11月起,澳大利来/新西兰的EMI申请合并;如果产品要在这二国销售,下列文件在行销前必备齐,以备ACA (Australian Communications Authority)或新西兰 (Ministry of Economic Development) 当局随时抽查:

1. 测试报告 - 必须由 NATA 或与 NATA 互让之认证机构,如 NVLAP 或 A2LA 认可的实验室核发才有效,否则要求样品送测机率非常高。

2. "Application to use the C-tick Mark" Form - 必须由澳大利亚/新西兰公司或进口商签名负责 。

3. "Supplier's Declaration of Conformity" Form -必须由澳大利亚/新西兰公司或进口商签名负责。 签名负责之厂商,有责任确保销售之产品仍符合EMI方面的规定。

4. 原始之设计图稿及规格书(如:线路图、方块图、User's Manual 和 Service Manual 等)。

5. 叙述制作时之生产检查程序,以确保 EMI 特性之维持。

6. 任何会影响到 EMI 的变更叙述和必要之测试记录。

C-tick认证周期

  C-tick认证周期: 1-2周

C-tick认证三个级别产品

  澳大利亚的EMC体系把产品划分为三个级别,供应商在销售级别二、级别三产品前,必须在ACA注册,申请使用C-Tick标志。

  级别一产品是指对使用无线频谱的设备干扰辐射较低的产品,如手动开关、简单的继电器、单向鼠笼式电感电机、电阻等。对级别一的产品,供应商必须签署符合性声明和提供产品描述书。级别一的产品可以自愿申请C-Tick标志,但是供应商在选择使用该标志后,在提供符合性声明和产品描述书的同时,还要提供符合性记录,以证明声明中所描述的产品已符合了相关的EMC标准。测试地点不作要求,允许内部测试。

  级别二产品是指对使用无线频谱的设备干扰辐射较高的产品,如开关电源、电焊机、调光器、大部分的家用电器等。供应商除了必须签署符合性申明和提供产品描述书外,还要提供按相关标准进行的测试报告,如果没有相关标准,则需要提供技术结构文件,测试地点不作要求,允许内部测试。

  级别三产品是指对使用无线频谱的设备干扰辐射极高的产品,即CISPR11与CISPR22覆盖的产品。目前,通信终端产品仍就包含在此范围内,但是从2003年11月7日起,终端产品将被划分到级别二产品中。供应商除了必须签署符合性申明和提供产品描述书外,还要提供由认可的测试机构出具的测试报告。同时还要出具由QSM认证机构颁发的质量管理体系证书。


A / C-Tick is by the Australian Communications Authority (Australian Communications Authority, referred to as ACA) issued to telecommunications equipment certification mark. Manufacturers and the import step-by-step more steps must be used in accordance with the A-Tick:
1, product implementation of technical standards ACAQ test
2, the ACA registered A / C-Tick
3, fill in "in line with the statement table "(Declaration of Conformity Form), and in line with the record keeping and products with
4, in communication products or equipment have put A / C-Tick mark logos (label) 5, for sale to consumers only the A-Tick applicable to communication products, electronic products to apply for most C-Tick, electronic products, however if the application A-Tick, you do not need to apply for C-Tick.

Since starting in November 2001, to Australia / New Zealand to apply for the merger of EMI; if the two countries in this sale, the following documents required before marketing Qi, for ACA (Australian Communications Authority) or New Zealand (Ministry of Economic Development) inspection authorities at any time:
1. test report - must be NATA or NATA certification of mutual institutions, such as NVLAP or A2LA accredited laboratory issued to be valid, otherwise the request to send the sample measured very high probability .
2. "Application to use the C-tick Mark" Form - must be from Australia / New Zealand company or importer is responsible for the signature.
3. "Supplier's Declaration of Conformity" Form - must be from Australia / New Zealand company or importer is responsible for the signature. Signed in charge of the vendor's responsibility to ensure that sales of the product continues to meet EMI requirements.
4. The original draft of the design drawings and specifications (such as: circuit diagram, block diagram, User's Manual and Service Manual, etc.).
5. Described the production of the production inspection procedures to ensure the maintenance of EMI characteristics.
6. Anything that would affect the EMI and the necessary changes described in the test record.


C-TICK certification preparation information

Quantity: At least two machine

C-TICK prepared:

1) Application Form for International Certification
2) nameplate
3) circuit schematic
4) Manual
5) Note the difference (when the application of a number of models)
6) key Components list (recommended the use of components of the international certification mark)
7) specification of some components (such as transformers, filters, fuses, capacitors, switches, etc.)
The above information needs

English!

Test cycle: complete information, products, under the premise of no improvement for 7 days!
